400 class pintle chains are of one-piece cast offset link construction joined together by steel pins. The pins are securely locked against turning in the sidebars by generous head stops that are cast on the links. The head stops are positioned to provide maximum locking effect when the chain is under load. This confines the wear to the part of the pin inside the barrel of the link, where it is distributed over the maximum area. This insures the best durability of the chain.
400 class pintle chains are links cast of high grade copper bearing malleable iron or Duramal. Duramal is a heat treated malleable iron having greater strength and superior resistance to wear and abrasion. Duramal chains have heat treated pins.
Riveted construction is furnished unless cottered construction is requested.
400 class pintle chains are interchangeable with other standard makes of corresponding sizes and numbers.
When furnished with attachments, 400 class pintle chains are normally used for conveyors and elevators where much slower speeds are recommended.
The maximum speed of this chain is generally 450 FPM, but depends upon size of sprockets. For Drive Service see Table 10, Section A. For Conveyor Service see Table 2, Section A.
Product Configuration
Find your Specific Chain!
Let us help you narrow down your search. Give us some of the details you need for your application and we will see what we can find!
Have a Unique Need?
We Can Help with That as Well!
400 Class 488 Product Information
Dimensions are in inches unless otherwise noted.
Dimensions:
Average Pitch
2.609
Barrel Length
1.625
Barrel Length
1.625
Barrel Length
1.625
Barrel Length
1.625
Barrel Length
1.625
Barrel Length
1.625
Barrel Length
1.625
Strengths:
Average Ultimate Strength in Lbs.
Malleable
11,000
Duramal
13,750
Average Ultimate Strength in Lbs.
Malleable
11,000
Duramal
13,750
General:
Approximate Links in 10 Ft.
2.9
