Dimensions are in inches unless otherwise noted.
| Chain No. | Chain Type | Average Pitch Inches | Sidebars | Pin Dia. | Pin Material | Bushing / Barrel | Roller | Average Ultimate | Rated Working | Chain id | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Thk. | Height | Sidebar Style | Material | Dia. | Length | Max Spkt. Width | Material | Dia. | Style | Material | Strength In Lbs. | Load In Lbs. | |||||||||||||
| 130 | Cast | 4 | 1 5/8 | 1 | 1 | 1 11/16 | 1 | 15,000 ML | 2,110 DUR | 778 | ||||||||||||||||
| 138 | Cast | 4 | 1 21/32 | 15/16 | 15/16 | 1 5/8 | 1 | 15,000 ML | 2,110 DUR | 778 | ||||||||||||||||
| 1706 | SBR | 12 | 1/2 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 120,000 | 14,000 | 783 | |||||||||
| 3939 | SBR | 8 | 5/32 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 19/32 | Carbon Steel, Heat Treated | 29/32 | A- Plain | Carbon Steel, Heat Treated | 24,000 | 2,500 | 783 | |||||||||
| 4103 | Cast | 3.075 | 1 1/2 | OFFSET | 3/4 | 1 1/4 | 1 7/8 | 1 1/8 | 22,000 ML | 27,500 DUR | 3,515 ML | 4,218 DUR | 772 | ||||||||||||||
| 4124 | Cast | 4.063 | 1 3/4 | OFFSET | 13/16 | 1 11/16 | 2 1/4 | 1 1/4 | 33,000 ML | 41,250 DUR | 4,570 ML | 5,485 DUR | 772 | ||||||||||||||
| 442 | Cast | 1.375 | 3/4 | OFFSET | 5/16 | 9/16 | 1 1/16 | 5/8 | 6,000 ML | 7,500 DUR | 830 ML | 995 DUR | 772 | ||||||||||||||
| 445 | Cast | 1.63 | 23/32 | OFFSET | 5/16 | 5/8 | 1 1/16 | 11/16 | 6,000 ML | 7,500 DUR | 830 ML | 995 DUR | 772 | ||||||||||||||
| 452 | Cast | 1.506 | 27/32 | OFFSET | 3/8 | 11/16 | 1 1/8 | 5/8 | 7,000 ML | 8,750 DUR | 1,055 ML | 1,265 DUR | 772 | ||||||||||||||
| 455 | Cast | 1.63 | 13/16 | OFFSET | 3/8 | 5/8 | 1 1/8 | 11/16 | 7,300 ML | 9,125 DUR | 1,055 ML | 1,265 DUR | 772 | ||||||||||||||
| 462 | Cast | 1.634 | 15/16 | OFFSET | 7/16 | 13/16 | 1 7/16 | 7/8 | 9,000 ML | 11,250 DUR | 1,500 ML | 1,800 DUR | 772 | ||||||||||||||
| 477 | Cast | 2.308 | 1 | OFFSET | 7/16 | 13/16 | 1 1/4 | 11/16 | 9,600 ML | 12,000 DUR | 1,365 ML | 1,640 DUR | 772 | ||||||||||||||
| 488 | Cast | 2.609 | 15/16 | OFFSET | 7/16 | 7/8 | 1 5/8 | 15/16 | 11,000 ML | 13,750 DUR | 1,775 ML | 2,130 DUR | 772 | ||||||||||||||
| 6104 | Cast | 6 | 3/8 | 1 1/2 | OFFSET | 3/4 | 5 1/2 | 3 13/16 | 52,500 ML | 8,750 DUR | 776 | |||||||||||||||
| 6110 | Cast | 6 | 3/8 | 1 1/2 | OFFSET | 3/4 | 10 1/2 | 9 | 52,500 ML | 8,750 DUR | 776 | |||||||||||||||
| 720 | Cast | 6 | 1 1/2 | OFFSET | 11/16 | 1 3/8 | 1 1/8 | 27,500 ML | 3,860 DUR | 774 | ||||||||||||||||
| 720NCS | Cast | 6 | 1 9/16 | OFFSET | 3/4 | 1 7/16 | 1 1/8 | 37,500 ML | 4,245 DUR | 774 | ||||||||||||||||
| 720S | Cast | 6 | 1 9/16 | OFFSET | 3/4 | 1 7/16 | 1 1/8 | 37,500 ML | 4,245 DUR | 774 | ||||||||||||||||
| 730 | Cast | 6 | 1 3/4 | OFFSET | 3/4 | 1 1/2 | 1 1/8 | 40,000 ML | 4,500 DUR | 774 | ||||||||||||||||
| 730NCS | Cast | 6 | 1 3/4 | OFFSET | 3/4 | 1 1/2 | 1 5/32 | 40,000 ML | 4,500 DUR | 774 | ||||||||||||||||
| 730S | Cast | 6 | 1 3/4 | OFFSET | 3/4 | 1 1/2 | 1 1/4 | 40,000 ML | 4,500 DUR | 774 | ||||||||||||||||
| 809 | SBR | 9 | 1/4 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 33,000 | 6,500 | 783 | |||||||||
| 8116 | Cast | 8 | 3/8 | 1 5/8 | OFFSET | 3/4 | 14 5/16 | 12 3/8 | 52,500 ML | 8,750 DUR | 776 | |||||||||||||||
| 81X | SBR | 2.609 | 5/32 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 19/32 | Carbon Steel, Heat Treated | 29/32 | A- Plain | Carbon Steel, Heat Treated | 24,000 | 2,500 | 783 | |||||||||
| 81XH | SBR | 2.609 | 5/16 | 1 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 19/32 | Carbon Steel, Heat Treated | 29/32 | A- Plain | Carbon Steel, Heat Treated | 33,000 | 2,750 | 783 | |||||||||
| 81XHH | SBR | 2.609 | 5/16 | 1 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 19/32 | Carbon Steel, Heat Treated | 29/32 | A- Plain | Carbon Steel, Heat Treated | 42,000 | 3,100 | 783 | |||||||||
| 8480 | Cast | 8 | 1/2 | 2 | OFFSET | 7/8 | 12 3/4 | 10 1/2 | 70,000 ML | 11,670 DUR | 776 | |||||||||||||||
| 907-E51 | Cast | 3.17 | OFFSET | 1 7/16 | 1 3/32 | 31,250 | 4,920 | 777 | |||||||||||||||||
| 907-R51 | Cast | 3.17 | OFFSET | 1 13/32 | 1 1/16 | 31,250 | 4,920 | 777 | |||||||||||||||||
| C188 | Combination | 2.609 | 1/4 | 1 1/8 | STRAIGHT | 1/2 | 7/8 | 1 9/16 | 17,500 | 2,340 | 780 | ||||||||||||||
| C188WS | Combination | 2.609 | 1/4 | 1 1/8 | STRAIGHT | 1/2 | 7/8 | 1 9/16 | 17,500 | 2,340 | 781 | ||||||||||||||
| C55 | Combination | 1.631 | 3/16 | 3/4 | STRAIGHT | 3/8 | 23/32 | 1 7/32 | 11,250 | 1,370 | 780 | ||||||||||||||
| C55D | Cast | 1.631 | 1 1/4 | STRAIGHT | 3/8 | 1 3/16 | 11/16 | 9,000 ML | 1,140 DUR | 779 | ||||||||||||||||
| CC5 | SBR | 6 | 5/16 | 2 1/2 | STRAIGHT | Carbon Steel | 11/16 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 4,800 | 783 | |||||||||
| CR188 | Combination | 2.609 | 1/4 | 1 1/8 | STRAIGHT | 1/2 | 7/8 | 1 9/16 | 15/16 | 1 1/2 | 17,500 | 2,340 | 782 | ||||||||||||
| CRN110 | Combination | 6 | 3/8 | 1 1/2 | STRAIGHT | 5/8 | 1 1/4 | 2 7/8 | 1 15/16 | 2 | 30,000 | 4,800 | 782 | ||||||||||||
| CRN111 | Combination | 4.76 | 3/8 | 1 3/4 | STRAIGHT | 3/4 | 1 7/16 | 3 3/8 | 2 3/8 | 2 1/4 | 45,000 | 7,500 | 782 | ||||||||||||
| CRN131 | Combination | 3.075 | 3/8 | 1 1/2 | STRAIGHT | 5/8 | 1 1/4 | 2 | 1 1/8 | 2 | 30,000 | 3,750 | 782 | ||||||||||||
| CRN132 | Combination | 6.05 | 1/2 | 2 | STRAIGHT | 1 | 1 3/4 | 4 3/8 | 3 1/8 | 3 | 62,500 | 10,400 | 782 | ||||||||||||
| DF3498 | Double Flex | 1.75 | 1 3/8 | STRAIGHT | 5/8 | 5/8 | 797 | ||||||||||||||||||
| DF3500 | Double Flex | 2.5 | 1 1/4 | STRAIGHT | 5/8 | 5/8 | 797 | ||||||||||||||||||
| DW111 | Combination | 4.76 | 3/8 | 1 3/4 | STRAIGHT | 3/4 | 1 7/16 | 3 3/8 | 45,000 | 7,500 | 781 | ||||||||||||||
| DW132 | Combination | 6.05 | 1/2 | 2 | STRAIGHT | 1 | 1 3/4 | 4 3/8 | 62,500 | 10,400 | 781 | ||||||||||||||
| H102 | Cast | 5 | 1 1/2 | OFFSET | 5/8 | 7 3/4 | 6 3/8 | 35,000 ML | 5,830 DUR | 775 | ||||||||||||||||
| H104P | Cast | 6 | 1 1/2 | OFFSET | 5/8 | 5 5/16 | 4 1/8 | 35,000 ML | 5,830 DUR | 775 | ||||||||||||||||
| H104W | Cast | 6 | 1 1/2 | OFFSET | 5/8 | 5 5/16 | 4 1/8 | 35,000 ML | 5,830 DUR | 775 | ||||||||||||||||
| H110 | Cast | 6 | 1 1/2 | OFFSET | 5/8 | 10 5/8 | 9 | 35,000 ML | 5,830 DUR | 775 | ||||||||||||||||
| H112 | Cast | 8 | 1 1/2 | OFFSET | 5/8 | 10 5/8 | 9 | 35,000 ML | 5,830 DUR | 775 | ||||||||||||||||
| H113 | Cast | 6 | 1 9/16 | OFFSET | 3/4 | 10 5/8 | 9 | 37,500 ML | 6,400 DUR | 775 | ||||||||||||||||
| H116 | Cast | 8 | 1 5/8 | OFFSET | 5/8 | 14 7/16 | 12 1/2 | 35,000 ML | 5,830 DUR | 775 | ||||||||||||||||
| H120 | Cast | 6 | 2 | OFFSET | 3/4 | 10 1/8 | 8 3/4 | 47,500 ML | 7,920 DUR | 775 | ||||||||||||||||
| H124 | Cast | 4 | 1 9/16 | OFFSET | 3/4 | 1 7/16 | 2 3/4 | 30,000 ML | 37,500 DUR | 5,000 ML | 6,000 DUR | 773 | |||||||||||||||
| H480 | Cast | 8 | 2 | OFFSET | 3/4 | 12 11/16 | 11 1/8 | 50,000 ML | 8,330 DUR | 775 | ||||||||||||||||
| H60 | Cast | 2.308 | 3/4 | OFFSET | 5/16 | 3/4 | 1 1/2 | 7,000 ML | 8,750 DUR | 1,170 ML | 1,400 DUR | 773 | |||||||||||||||
| H62 | Cast | 1.654 | 13/16 | OFFSET | 5/16 | 13/16 | 1 5/16 | 7,000 ML | 8,750 DUR | 1,030 ML | 1,235 DUR | 773 | |||||||||||||||
| H74 | Cast | 2.609 | 1 | OFFSET | 3/8 | 7/8 | 1 5/8 | 10,000 ML | 12,500 DUR | 1,525 ML | 1,830 DUR | 773 | |||||||||||||||
| H78 | Cast | 2.609 | 1 1/8 | OFFSET | 1/2 | 7/8 | 1 7/8 | 16,000 ML | 20,000 DUR | 2,340 ML | 2,810 DUR | 773 | |||||||||||||||
| H78B | Cast | 2.609 | 1 1/16 | 7/8 | 1 13/16 | 1 1/8 | 16,000 ML | 2,350 DUR | 778 | |||||||||||||||||
| H82 | Cast | 3.075 | 1 1/4 | OFFSET | 9/16 | 1 7/32 | 2 3/16 | 20,000 ML | 25,000 DUR | 3,080 ML | 3,695 DUR | 773 | |||||||||||||||
| H85 | Cast | 4 | 1 | OFFSET | 7/16 | 31/32 | 2 5/8 | 12,500 ML | 15,625 DUR | 2,080 ML | 2,600 DUR | 773 | |||||||||||||||
| HSB102½ | HSB Rollerless | 4.04 | 3/8 | 1 3/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 3/8 | Alloy Steel, Heat Treated | 50,000 | 7,700 | 784 | ||||||||||||
| HSB102B | HSB Rollerless | 4 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 40,000 | 6,290 | 784 | ||||||||||||
| HSB110 | HSB Rollerless | 6 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 40,000 | 6,290 | 784 | ||||||||||||
| HSB111 | HSB Rollerless | 4.76 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | Carbon Steel, Heat Treated | 50,000 | 8,850 | 784 | ||||||||||||
| HSB111SPC | HSB Rollerless | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | Carbon Steel, Heat Treated | 50,000 | 4.760 7.240 | 8,850 | 784 | |||||||||||
| HSB1219 | HSB Rollerless | 9 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | Carbon Steel, Heat Treated | 50,000 | 8,850 | 784 | ||||||||||||
| HSB1259 | HSB Rollerless | 12 | 5/8 | 3 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 21,875 | 784 | ||||||||||||
| HSB131 | HSB Rollerless | 3.075 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 40,000 | 4,380 | 784 | ||||||||||||
| HSB1316 | HSB Rollerless | 6 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 40,000 | 4,650 | 784 | ||||||||||||
| HSB150+ | HSB Rollerless | 6.05 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 15,100 | 784 | ||||||||||||
| HSB1654 | HSB Rollerless | 6 | 5/8 | 4 | OFFSET | Carbon Steel, Heat Treated | 1 1/2 | Alloy Steel, Heat Treated | 2 1/2 | Alloy Steel, Heat Treated | 230,000 | 18,375 | 784 | ||||||||||||
| HSB1663 | HSB Rollerless | 2.609 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 38,000 | 3,200 | 784 | ||||||||||||
| HSB1856 | HSB Rollerless | 8 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 14,000 | 784 | ||||||||||||
| HSB187 | HSB Rollerless | 8 | 1/4 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 25,000 | 2,730 | 784 | ||||||||||||
| HSB188 | HSB Rollerless | 2.609 | 1/4 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 25,000 | 2,730 | 784 | ||||||||||||
| HSB1903 | HSB Rollerless | 9 | 1/2 | 3 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 110,000 | 15,100 | 784 | ||||||||||||
| HSB1956 | HSB Rollerless | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 14,000 | 784 | ||||||||||||
| HSB2730 | HSB Rollerless | 6 | 3/8 | 1 3/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 50,000 | 5,575 | 784 | ||||||||||||
| HSB2858A | HSB Rollerless | 6 | 1/2 | 3 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 150,000 | 15,300 | 784 | ||||||||||||
| HSB2866 | HSB Rollerless | 7 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1.36 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 27,370 | 784 | ||||||||||||
| HSB4933 | HSB Rollerless | 4.04 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 3/8 | Alloy Steel, Heat Treated | 72,000 | 9,200 | 784 | ||||||||||||
| HSB5131 | HSB Rollerless | 5 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 40,000 | 4,380 | 784 | ||||||||||||
| HSB61021/2 | HSB Rollerless | 12 | 3/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 3/8 | Alloy Steel, Heat Treated | 50,000 | 7,700 | 784 | ||||||||||||
| HSB6124 | HSB Rollerless | 12 | 1/2 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 10,500 | 784 | ||||||||||||
| HSB6322 | HSB Rollerless | 12 | 3/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 50,000 | 7,200 | 784 | ||||||||||||
| HSB6472 | HSB Rollerless | 4.04 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 3/8 | Alloy Steel, Heat Treated | 72,000 | 6,125 | 784 | ||||||||||||
| HSB825 | HSB Rollerless | 4 | 3/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 60,000 | 5,900 | 784 | ||||||||||||
| HSB826 | HSB Rollerless | 6 | 3/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 95,000 | 9,570 | 784 | ||||||||||||
| HSB830 | HSB Rollerless | 6 | 3/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 60,000 | 5,900 | 784 | ||||||||||||
| HSB833 | HSB Rollerless | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | Carbon Steel, Heat Treated | 50,000 | 8,850 | 784 | ||||||||||||
| HSB835 | HSB Rollerless | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 60,000 | 5,900 | 784 | ||||||||||||
| HSB844 | HSB Rollerless | 6 | 1/2 | 2 | STRAIGHT or OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 65,000 | 9,200 | 784 | ||||||||||||
| HSB850 | HSB Rollerless | 6 | 5/8 | 3 | STRAIGHT or OFFSET | Carbon Steel, Heat Treated | 1 5/16 | Alloy Steel, Heat Treated | 2 | Alloy Steel, Heat Treated | 200,000 | 16,000 | 784 | ||||||||||||
| HSB851 | HSB Rollerless | 6 | 5/8 | 3 1/2 | STRAIGHT or OFFSET | Carbon Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 24,500 | 784 | ||||||||||||
| HSB852 | HSB Rollerless | 12 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 15,100 | 784 | ||||||||||||
| HSB856B | HSB Rollerless | 6 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 14,000 | 784 | ||||||||||||
| HSB857A | HSB Rollerless | 6 | 1/2 | 3 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 130,000 | 14,000 | 784 | ||||||||||||
| HSB859B | HSB Rollerless | 6 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 21,875 | 784 | ||||||||||||
| HSB860B | HSB Rollerless | 6 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 10,500 | 784 | ||||||||||||
| HSB864B | HSB Rollerless | 7 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 21,875 | 784 | ||||||||||||
| HSB886 | HSB Rollerless | 7 | 3/4 | 4 | OFFSET | Carbon Steel, Heat Treated | 1 5/8 | Alloy Steel, Heat Treated | 2 5/8 | Alloy Steel, Heat Treated | 350,000 | 24,200 | 784 | ||||||||||||
| HSB9124 | HSB Rollerless | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 10,500 | 784 | ||||||||||||
| HSB9150 | HSB Rollerless | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 15,100 | 784 | ||||||||||||
| HSB956 | HSB Rollerless | 6 | 1/2 | 3 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 100,000 | 14,000 | 784 | ||||||||||||
| HSB959 | HSB Rollerless | 9 | 5/8 | 3 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 21,875 | 784 | ||||||||||||
| HSB964 | HSB Rollerless | 9 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 200,000 | 21,875 | 784 | ||||||||||||
| HSB984 | HSB Rollerless | 7 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 3/8 | Alloy Steel, Heat Treated | 2 1/2 | Alloy Steel, Heat Treated | 200,000 | 24,000 | 784 | ||||||||||||
| N102 1/2 | Combination | 4.04 | 3/8 | 1 3/4 | STRAIGHT | 3/4 | 1 3/8 | 2 15/16 | 45,000 | 6,600 | 780 | ||||||||||||||
| N102B | Combination | 4 | 3/8 | 1 1/2 | STRAIGHT | 5/8 | 1 | 2 7/8 | 30,000 | 5,000 | 780 | ||||||||||||||
| N110 | Combination | 6 | 3/8 | 1 1/2 | STRAIGHT | 5/8 | 1 1/4 | 2 7/8 | 30,000 | 5,000 | 780 | ||||||||||||||
| N111 | Combination | 4.76 | 3/8 | 1 3/4 | STRAIGHT | 3/4 | 1 7/16 | 3 3/8 | 45,000 | 7,500 | 780 | ||||||||||||||
| N111SPC | Combination | 6 | 3/8 | 1 3/4 | STRAIGHT | 3/4 | 1 7/16 | 3 3/8 | 45,000 | 7,500 | 780 | ||||||||||||||
| N131 | Combination | 3.075 | 3/8 | 1 1/2 | STRAIGHT | 5/8 | 1 1/4 | 2 | 30,000 | 3,750 | 780 | ||||||||||||||
| N131WS | Combination | 3.075 | 3/8 | 1 1/2 | STRAIGHT | 5/8 | 1 1/4 | 2 | 30,000 | 3,750 | 781 | ||||||||||||||
| N132 | Combination | 6.05 | 1/2 | 2 | STRAIGHT | 1 | 1 3/4 | 4 3/8 | 62,500 | 10,400 | 780 | ||||||||||||||
| N132WS | Combination | 6.05 | 1/2 | 2 | STRAIGHT | 1 | 1 3/4 | 4 3/8 | 62,500 | 10,400 | 781 | ||||||||||||||
| N77 | Combination | 2.308 | 3/16 | 7/8 | STRAIGHT | 7/16 | 23/32 | 1 1/4 | 13,750 | 1,640 | 780 | ||||||||||||||
| RS1211F | SBR | 12 | 5/16 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 38,000 | 4,650 | 783 | |||||||||
| RS1211P | SBR | 12 | 5/16 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | B- Plain with Hubs | WEBLOY | 38,000 | 4,650 | 783 | |||||||||
| RS1221½P | SBR | 12 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/4 | D- Plain with Core | Carbon Steel, Heat Treated | 50,000 | 6,230 | 783 | |||||||||
| RS1221P | SBR | 12 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/4 | D- Plain with Core | WEBLOY | 50,000 | 6,230 | 783 | |||||||||
| RS1222F | SBR | 12 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1222P | SBR | 12 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1228 | SBR | 12 | 3/8 | 2 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 7/8 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 7,200 | 783 | |||||||||
| RS1232F | SBR | 12 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1232P | SBR | 12 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1233½P | SBR | 12 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 56,000 | 9,200 | 783 | |||||||||
| RS1233F | SBR | 12 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS1233P | SBR | 12 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS1238 | SBR | 12 | 3/8 | 2 1/2 | OFFSET | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 1 7/8 | A- Plain | Carbon Steel, Heat Treated | 56,000 | 9,200 | 783 | |||||||||
| RS1244½P | SBR | 12 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 90,000 | 12,700 | 783 | |||||||||
| RS1244F | SBR | 12 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | G- Flanged with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS1244P | SBR | 12 | 1/2 | 21/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | D- Plain with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS1246 | SBR | 12 | 1/2 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 125,000 | 12,700 | 783 | |||||||||
| RS1255F | SBR | 12 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 6 | G- Flanged with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS1255P | SBR | 12 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 6 | D- Plain with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS1258F | SBR | 12 | 1/4 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 30,000 | 4,650 | 783 | |||||||||
| RS1258P | SBR | 12 | 1/4 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | D- Plain with Core | WEBLOY | 30,000 | 4,650 | 783 | |||||||||
| RS1422F | SBR | 14 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1422P | SBR | 14 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1822F | SBR | 18 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1822P | SBR | 18 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1832F | SBR | 18 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1832P | SBR | 18 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS1833F | SBR | 18 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS1833P | SBR | 18 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS1844F | SBR | 18 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | G- Flanged with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS1844P | SBR | 18 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | D- Plain with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS1855F | SBR | 18 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Carbon Steel, Heat Treated | 6 | G- Flanged with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS1855P | SBR | 18 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Carbon Steel, Heat Treated | 6 | D- Plain with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS1866F | SBR | 18 | 5/8 | 3 1/2 | STRAIGHT | Carbon Steel | 1 1/2 | Alloy Steel, Heat Treated | 2 | Carbon Steel, Heat Treated | 6 | G- Flanged with Core | WEBLOY | 150,000 | 22,300 | 783 | |||||||||
| RS2444F | SBR | 24 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | G- Flanged with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS2444P | SBR | 24 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | D- Plain with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS2455F | SBR | 24 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Carbon Steel, Heat Treated | 6 | G- Flanged with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS2455P | SBR | 24 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Carbon Steel, Heat Treated | 6 | D- Plain with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS2466F | SBR | 24 | 5/8 | 3 1/2 | STRAIGHT | Carbon Steel | 1 1/2 | Alloy Steel, Heat Treated | 2 | Carbon Steel, Heat Treated | 6 | G- Flanged with Core | WEBLOY | 150,000 | 22,300 | 783 | |||||||||
| RS611F | SBR | 6 | 5/16 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 42,000 | 4,650 | 783 | |||||||||
| RS611P | SBR | 6 | 5/16 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | B- Plain with Hubs | WEBLOY | 42,000 | 4,650 | 783 | |||||||||
| RS622F | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS622P | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS658F | SBR | 6 | 1/4 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 30,000 | 4,650 | 783 | |||||||||
| RS658P | SBR | 6 | 1/4 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | D- Plain with Core | WEBLOY | 30,000 | 4,650 | 783 | |||||||||
| RS822F | SBR | 8 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS822P | SBR | 8 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS832F | SBR | 8 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS832P | SBR | 8 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS833F | SBR | 8 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS833P | SBR | 8 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS911F | SBR | 9 | 5/16 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 38,000 | 4,650 | 783 | |||||||||
| RS911P | SBR | 9 | 5/16 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 3 | B- Plain with Hubs | WEBLOY | 38,000 | 4,650 | 783 | |||||||||
| RS922F | SBR | 9 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 3 1/2 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS922P | SBR | 9 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 3 1/2 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS928 | SBR | 9 | 3/8 | 2 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 7/8 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 7,200 | 783 | |||||||||
| RS932F | SBR | 9 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS932P | SBR | 9 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Carbon Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 50,000 | 7,200 | 783 | |||||||||
| RS933½P | SBR | 9 | 3/8 | 2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 56,000 | 9,200 | 783 | |||||||||
| RS933F | SBR | 9 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS933P | SBR | 9 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 4 | D- Plain with Core | WEBLOY | 56,000 | 9,200 | 783 | |||||||||
| RS938 | SBR | 9 | 3/8 | 2 1/2 | OFFSET | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 1 7/8 | A- Plain | Carbon Steel, Heat Treated | 56,000 | 9,200 | 783 | |||||||||
| RS944½P | SBR | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 90,000 | 12,700 | 783 | |||||||||
| RS944F | SBR | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | G- Flanged with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS944P | SBR | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/8 | Carbon Steel, Heat Treated | 5 | D- Plain with Core | WEBLOY | 90,000 | 12,700 | 783 | |||||||||
| RS946 | SBR | 9 | 1/2 | 2 1/2 | OFFSET | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 85,000 | 12,700 | 783 | |||||||||
| RS955F | SBR | 9 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 6 | G- Flanged with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS955P | SBR | 9 | 5/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 6 | D- Plain with Core | WEBLOY | 130,000 | 17,500 | 783 | |||||||||
| RS958F | SBR | 9 | 1/4 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 30,000 | 4,650 | 783 | |||||||||
| RS958P | SBR | 9 | 1/4 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 3 | D- Plain with Core | WEBLOY | 30,000 | 4,650 | 783 | |||||||||
| S1036 | SBR | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,650 | 783 | |||||||||
| S1112 | SBR | 3.69 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 1 3/4 | A- Plain | Carbon Steel, Heat Treated | 21,000 | 3,500 | 783 | |||||||||
| S1113 | SBR | 4.04 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,240 | 783 | |||||||||
| S1113D | Delrin Bushed | 4.04 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel, Zinc Plated | 5/8 | Alloy Steel, Zinc Plated | 7/8 | Stainless Steel, Heat Treated | 2 | Carbon Steel, Zinc Plated | 28,000 | 3,150 | 798 | ||||||||||
| S1114 | SBR | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,240 | 783 | |||||||||
| S1116 | SBR | 6 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 21,000 | 3,500 | 783 | |||||||||
| S1117 | SBR | 9 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 21,000 | 3,500 | 783 | |||||||||
| S1118 | SBR | 12 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 21,000 | 3,500 | 783 | |||||||||
| S1119 | SBR | 4 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 21,000 | 3,500 | 783 | |||||||||
| S1120 | SBR | 4 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,100 | 783 | |||||||||
| S1121 | SBR | 4 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| S1122 | SBR | 4 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 1 3/4 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| S1131 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 6,230 | 783 | |||||||||
| S1140 | SBR | 4 | 5/16 | 2 | STRAIGHT | Carbon Steel | 11/16 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 38,000 | 4,800 | 783 | |||||||||
| S1141 | SBR | 6 | 5/16 | 2 | STRAIGHT | Carbon Steel | 11/16 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 38,000 | 4,800 | 783 | |||||||||
| S11524 | Traveling Water Screen | 24 | 1/2 | 2 3/4 | STRAIGHT | Carbon Steel | 1 1/4 | Carbon Steel | 1 3/4 | Carbon Steel | 3 3/4 | Carbon Steel | 86,000 | 11,760 | 799 | ||||||||||
| S1183 | SBR | 3 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,100 | 783 | |||||||||
| S1184 | SBR | 3 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| S1195 | SBR | 4 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| S1196 | SBR | 6 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 21,700 | 2,490 | 783 | |||||||||
| S1197 | SBR | 6 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| S1198 | SBR | 6 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| S1199 | SBR | 6 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,100 | 783 | |||||||||
| S1209A | SBR | 9 | 5/8 | 3 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/2 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 4 1/4 | A- Plain | Carbon Steel, Heat Treated | 183,000 | 25,000 | 783 | |||||||||
| S1245 | SBR | 12 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 125,000 | 12,700 | 783 | |||||||||
| S1270 | SBR | 12 | 5/16 | 2 1/2 | STRAIGHT | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 4 | G- Flanged with Core | WEBLOY | 46,000 | 7,665 | 783 | |||||||||
| S13917 | Traveling Water Screen | 24 | 3/8 | 2 3/4 | STRAIGHT | Carbon Steel | 1 1/4 | Carbon Steel | 1 3/4 | Carbon Steel | 3 3/4 | Carbon Steel | 65,000 | 10,400 | 799 | ||||||||||
| S1478 | SBR | 4 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 27,000 | 2,730 | 783 | |||||||||
| S1500 | SBR | 1.5 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 13/16 | A- Plain | Carbon Steel, Heat Treated | 12,000 | 2,000 | 783 | |||||||||
| S15030 | Traveling Water Screen | 24 | 3/8 | 2 3/4 | STRAIGHT | Carbon Steel | 1 1/4 | Carbon Steel | 1 3/4 | Carbon Steel | 3 3/4 | Carbon Steel | 65,000 | 10,665 | 799 | ||||||||||
| S15041A | Traveling Water Screen | 24 | 3/8 | 3 | STRAIGHT | Carbon Steel | 1 1/4 | Carbon Steel | 1 3/4 | Carbon Steel | 4 | Carbon Steel | 65,000 | 9,850 | 799 | ||||||||||
| S1578 | SBR | 2.609 | 3/16 | 1 | OFFSET | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 7/8 | A- Plain | Carbon Steel, Heat Treated | 12,000 | 2,000 | 783 | |||||||||
| S1596 | SBR | 5 | 5/16 | 1 1/2 | OFFSET | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,240 | 783 | |||||||||
| S1602 | SBR | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 29/32 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 32,000 | 4,375 | 783 | |||||||||
| S1604 | SBR | 6 | 1/4 | 1 1/2 | OFFSET | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 27,000 | 2,730 | 783 | |||||||||
| S1670 | SBR | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,240 | 783 | |||||||||
| S1670D | Delrin Bushed | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel, Zinc Plated | 5/8 | Alloy Steel, Zinc Plated | 7/8 | Stainless Steel, Heat Treated | 2 1/4 | Carbon Steel, Zinc Plated | 28,000 | 3,150 | 798 | ||||||||||
| S1800+ | SBR | 3.075 | 1/4 | 1 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/8 | A- Plain | Carbon Steel, Heat Treated | 30,000 | 2,730 | 783 | |||||||||
| S1920 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 73,000 | 5,900 | 783 | |||||||||
| S2035 | SBR | 5.188 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 124,000 | 9,350 | 783 | |||||||||
| S2130 | SBR | 6 | 3/8 | 2 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 5,900 | 783 | |||||||||
| S2180 | SBR | 6 | 3/8 | 1 3/4 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 29/32 | Carbon Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 33,600 | 4,375 | 783 | |||||||||
| S2188 | SBR | 4 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 3/4 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,240 | 783 | |||||||||
| S2190 | SBR | 6 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 21,000 | 3,500 | 783 | |||||||||
| S2190F | SBR | 6 | 1/4 | 1 1/2 | STRAIGHT | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 2 1/2 | E- Flanged | WEBLOY | 21,000 | 3,500 | 783 | |||||||||
| S2219 | SBR | 3.675 | 1/4 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 1 1/8 | A- Plain | Alloy Steel, Heat Treated | 44,000 | 3,450 | 783 | |||||||||
| S2268 | SBR | 4.083 | 3/8 | 2 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 5/8 | A- Plain | Carbon Steel, Heat Treated | 62,600 | 7,220 | 783 | |||||||||
| S2268HD | SBR | 4.083 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | Alloy Steel, Heat Treated | 2 | A- Plain | Alloy Steel, Heat Treated | 100,000 | 8,400 | 783 | ||||||||||
| S2268SPC | SBR | 4.083 | 3/8 | 2 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 62,600 | 7,220 | 783 | |||||||||
| S2342 | SBR | 9 | 1/2 | 2 1/2 | OFFSET | Carbon Steel | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | A- Plain | Carbon Steel, Heat Treated | 65,000 | 9,000 | 783 | |||||||||
| S2400+ | SBR | 4 | 1/4 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 1 1/8 | A- Plain | Carbon Steel, Heat Treated | 44,000 | 3,570 | 783 | |||||||||
| S2436+ | SBR | 4 | 1/4 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 13/16 | Carbon Steel, Heat Treated | 1 1/8 | A- Plain | Alloy Steel, Heat Treated | 44,000 | 3,450 | 783 | |||||||||
| S2450+ | SBR | 4 | 5/16 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Alloy Steel, Heat Treated | 52,000 | 4,650 | 783 | |||||||||
| S2614 | SBR | 12 | 5/8 | 3 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 162,000 | 17,500 | 783 | |||||||||
| S2648 | SBR | 12 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 5/8 | Alloy Steel, Heat Treated | 2 1/2 | Alloy Steel, Heat Treated | 3 1/2 | A- Plain | Alloy Steel, Heat Treated | 200,000 | 29,600 | 783 | |||||||||
| S2847 | SBR | 6 | 5/16 | 1 3/4 | STRAIGHT | Carbon Steel, Heat Treated | 11/16 | Alloy Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 1 3/8 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 6,620 | 783 | |||||||||
| S3433 | SBR | 4 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 40,000 | 6,290 | 783 | |||||||||
| S3433SPC | SBR | 4 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 5/8 | A- Plain | Carbon Steel, Heat Treated | 40,000 | 6,290 | 783 | |||||||||
| S3600+ | SBR | 6 | 3/8 | 2 1/4 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 5/8 | A- Plain | Carbon Steel, Heat Treated | 77,000 | 7,200 | 783 | |||||||||
| S3940 | SBR | 6 | 3/8 | 2 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 5/8 | A- Plain | Carbon Steel, Heat Treated | 62,600 | 7,220 | 783 | |||||||||
| S3945 | SBR | 4 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Alloy Steel, Heat Treated | 40,000 | 5,740 | 783 | |||||||||
| S3945SPC | SBR | 4.09 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 3/8 | A- Plain | Alloy Steel, Heat Treated | 40,000 | 5,740 | 783 | |||||||||
| S3952 | SBR | 4 | 3/8 | 1 3/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 7/16 | A- Plain | Alloy Steel, Heat Treated | 40,000 | 7,220 | 783 | |||||||||
| S3968 | SBR | 4.61 | 5/16 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 3/8 | A- Plain | Carbon Steel, Heat Treated | 40,000 | 5,740 | 783 | |||||||||
| S4001 | SBR | 3 | 1/4 | 1 1/4 | STRAIGHT | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 19,000 | 2,730 | 783 | |||||||||
| S4002 | SBR | 4 | 1/4 | 1 1/4 | STRAIGHT | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 19,000 | 2,730 | 783 | |||||||||
| S4003 | SBR | 6 | 1/4 | 1 1/4 | STRAIGHT | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 19,000 | 2,730 | 783 | |||||||||
| S4004 | SBR | 9 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 85,000 | 12,700 | 783 | |||||||||
| S4009 | SBR | 9 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 81,200 | 9,200 | 783 | |||||||||
| S4019 | SBR | 4 | 1/4 | 1 1/4 | STRAIGHT | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | A- Plain | Carbon Steel, Heat Treated | 19,000 | 2,450 | 783 | |||||||||
| S4065A | SBR | 9 | 5/8 | 3 1/2 | STRAIGHT | Carbon Steel | 1 1/4 | Alloy Steel, Heat Treated | 2 | Alloy Steel, Heat Treated | 4 1/4 | A- Plain | Carbon Steel, Heat Treated | 150,000 | 18,900 | 783 | |||||||||
| S4830 | SBR | 4 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 40,000 | 6,290 | 783 | |||||||||
| S531 | SBR | 4 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 29/32 | Carbon Steel, Heat Treated | 2 1/4 | A- Plain | Carbon Steel, Heat Treated | 32,000 | 4,375 | 783 | |||||||||
| S554 | SBR | 3.075 | 5/16 | 1 1/2 | OFFSET | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,650 | 783 | |||||||||
| S554+ | SBR | 3.075 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 41,000 | 4,650 | 783 | |||||||||
| S588+ | SBR | 2.609 | 1/4 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 7/8 | A- Plain | Carbon Steel, Heat Treated | 27,890 | 2,490 | 783 | |||||||||
| S645 | SBR | 6 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 122,000 | 12,700 | 783 | |||||||||
| S6910 | SBR | 6 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 82,250 | 9,200 | 783 | |||||||||
| S788+ | SBR | 2.609 | 1/4 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 7/8 | A- Plain | Carbon Steel, Heat Treated | 27,890 | 2,490 | 783 | |||||||||
| S9063 | SBR | 6 | 3/8 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 15/16 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 140,000 | 7,380 | 783 | |||||||||
| S9111A | SBR | 4.76 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | Carbon Steel, Heat Treated | 1 7/8 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 8,850 | 783 | |||||||||
| S945 | SBR | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,650 | 783 | |||||||||
| S951 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 29/32 | Carbon Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 40,000 | 4,375 | 783 | |||||||||
| S9833A | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 8,850 | 783 | |||||||||
| S9856B | SBR | 6 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 2 13/16 | A- Plain | Carbon Steel, Heat Treated | 100,000 | 14,000 | 783 | |||||||||
| SR131 | SBR | 3.075 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 29/32 | Carbon Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 42,000 | 4,375 | 783 | |||||||||
| SS1776 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 1/2 | B- Plain with Hubs | Carbon Steel, Heat Treated | 50,000 | 5,900 | 783 | |||||||||
| SS3888 | SBR | 6 | 3/8 | 3 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 73,200 | 7,875 | 783 | |||||||||
| SS554 | SBR | 3.075 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,650 | 783 | |||||||||
| SS554+ | SBR | 3.075 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 41,000 | 4,650 | 783 | |||||||||
| SS555 | SBR | 4 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,650 | 783 | |||||||||
| SS556 | SBR | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 2 | A- Plain | Carbon Steel, Heat Treated | 28,000 | 4,650 | 783 | |||||||||
| SS556F | SBR | 6 | 5/16 | 1 1/2 | STRAIGHT | Carbon Steel | 5/8 | Alloy Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 3 | E- Flanged | WEBLOY | 28,000 | 4,650 | 783 | |||||||||
| SS6 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 1/2 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 5,575 | 783 | |||||||||
| SS6SPC | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 5,575 | 783 | |||||||||
| SS881 | SBR | 2.609 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 7/8 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,300 | 783 | |||||||||
| SS881+ | SBR | 2.609 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 7/8 | A- Plain | Carbon Steel, Heat Treated | 27,890 | 2,490 | 783 | |||||||||
| SS888 | SBR | 8 | 3/16 | 1 1/8 | STRAIGHT | Carbon Steel | 7/16 | Alloy Steel, Heat Treated | 5/8 | Carbon Steel, Heat Treated | 7/8 | A- Plain | Carbon Steel, Heat Treated | 14,000 | 2,100 | 783 | |||||||||
| SS9061 | SBR | 6 | 3/8 | 2 1/4 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 3/4 | A- Plain | Carbon Steel, Heat Treated | 85,000 | 5,900 | 783 | |||||||||
| SS944+ | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 7/8 | A- Plain | Carbon Steel, Heat Treated | 73,000 | 5,900 | 783 | |||||||||
| SS96 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 3/4 | A- Plain | Carbon Steel, Heat Treated | 50,000 | 5,900 | 783 | |||||||||
| SS996 | SBR | 6 | 3/8 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 2 3/4 | A- Plain | Carbon Steel, Heat Treated | 73,000 | 5,900 | 783 | |||||||||
| TS856 | HSB Rollerless | 6 | 1/2 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 150,000 | 14,000 | 785 | ||||||||||||
| TS857 | HSB Rollerless | 6 | 1/2 | 3 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 150,000 | 14,000 | 785 | ||||||||||||
| TS859 | HSB Rollerless | 6 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 250,000 | 21,875 | 785 | ||||||||||||
| TS864 | HSB Rollerless | 7 | 5/8 | 4 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/8 | Alloy Steel, Heat Treated | 250,000 | 21,875 | 785 | ||||||||||||
| TS956 | HSB Rollerless | 6 | 1/2 | 3 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | Alloy Steel, Heat Treated | 150,000 | 14,000 | 785 | ||||||||||||
| WD102 | Portalloy® Drag | 5 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 51,000 | 8,500 | 791 | ||||||||||||
| WD104 | Portalloy® Drag | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 51,000 | 8,500 | 791 | ||||||||||||
| WD112 | Portalloy® Drag | 8 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 51,000 | 8,500 | 791 | ||||||||||||
| WD113 | Portalloy® Drag | 6 | 1/2 | 1 1/2 | OFFSET | Carbon Steel | 7/8 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 55,000 | 9,200 | 791 | ||||||||||||
| WD116 | Portalloy® Drag | 8 | 3/8 | 1 3/4 | OFFSET | Carbon Steel | 3/4 | Carbon Steel, Heat Treated | 1 3/4 | Carbon Steel | 55,000 | 9,200 | 791 | ||||||||||||
| WD118 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 70,000 | 11,700 | 791 | ||||||||||||
| WD120 | Portalloy® Drag | 6 | 1/2 | 2 | OFFSET | Carbon Steel | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 70,000 | 11,700 | 791 | ||||||||||||
| WD122 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 70,000 | 11,700 | 791 | ||||||||||||
| WD480 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 70,000 | 11,700 | 791 | ||||||||||||
| WDH102 | Portalloy® Drag | 5 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 60,000 | 10,000 | 791 | ||||||||||||
| WDH104 | Portalloy® Drag | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 60,000 | 10,000 | 791 | ||||||||||||
| WDH110 | Portalloy® Drag | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 60,000 | 10,000 | 791 | ||||||||||||
| WDH112 | Portalloy® Drag | 8 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 60,000 | 10,000 | 791 | ||||||||||||
| WDH113 | Portalloy® Drag | 6 | 1/2 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 1 1/2 | Carbon Steel | 70,000 | 11,700 | 791 | ||||||||||||
| WDH116 | Portalloy® Drag | 8 | 3/8 | 1 3/4 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 3/4 | Carbon Steel | 69,000 | 11,500 | 791 | ||||||||||||
| WDH118 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 90,000 | 15,000 | 791 | ||||||||||||
| WDH118HD | Portalloy® Drag | 8 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel, Heat Treated | 134,000 | 22,300 | 885 | ||||||||||||
| WDH120 | Portalloy® Drag | 6 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 90,000 | 15,000 | 791 | ||||||||||||
| WDH120HD | Portalloy® Drag | 6 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel, Heat Treated | 134,000 | 22,300 | 885 | ||||||||||||
| WDH122 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 90,000 | 15,000 | 791 | ||||||||||||
| WDH122HD | Portalloy® Drag | 8 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel, Heat Treated | 134,000 | 22,300 | 885 | ||||||||||||
| WDH480 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 90,000 | 15,000 | 791 | ||||||||||||
| WDH480HD | Portalloy® Drag | 8 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel, Heat Treated | 134,000 | 22,300 | 885 | ||||||||||||
| WDH520 | Portalloy® Drag | 6 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 103,000 | 17,200 | 791 | ||||||||||||
| WDH522 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 103,000 | 17,200 | 791 | ||||||||||||
| WDH580 | Portalloy® Drag | 8 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 123,000 | 20,500 | 791 | ||||||||||||
| WDH680 | Portalloy® Drag | 8 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Carbon Steel, Heat Treated | 2 | Carbon Steel | 134,000 | 22,300 | 791 | ||||||||||||
| WH106 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 7,200 | 882 | |||||||||||
| WH106HD | Portalloy® Mill | 6 | 1/2 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 92,500 | 7,875 | 882 | |||||||||||
| WH106XHD | Portalloy® Mill | 6.05 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Induction Hardened | 1 3/4 | 1 1/2 | Carbon Steel, Heat Treated | 115,000 | 10,500 | 882 | |||||||||||
| WH110 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 3/4 | Carbon Steel, Heat Treated | 69,000 | 7,875 | 882 | |||||||||||
| WH111+ | Portalloy® Mill | 4.76 | 3/8 | 1 3/4 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 2 | Carbon Steel, Heat Treated | 77,000 | 8,850 | 882 | |||||||||||
| WH111+HD | Portalloy® Mill | 4.76 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | 2 | Carbon Steel, Heat Treated | 77,000 | 9,500 | 882 | |||||||||||
| WH124 | Portalloy® Mill | 4 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 7,200 | 882 | |||||||||||
| WH124HDSPC | Portalloy® Mill | 4.063 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | 1 1/2 | Carbon Steel, Heat Treated | 100,000 | 10,500 | 882 | |||||||||||
| WH124XHD | Portalloy® Mill | 4.063 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Induction Hardened | 1 3/4 | 1 1/2 | Carbon Steel, Heat Treated | 129,000 | 11,375 | 882 | |||||||||||
| WH132 | Portalloy® Mill | 6.05 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 115,000 | 15,300 | 882 | |||||||||||
| WH132HD | Portalloy® Mill | 6.05 | 5/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 152,000 | 16,200 | 882 | |||||||||||
| WH132XHD | Portalloy® Mill | 6.05 | 3/4 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 182,000 | 17,000 | 882 | |||||||||||
| WH144 | Portalloy® Mill | 4 | 3/8 | 1 3/4 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 5/8 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 9,600 | 882 | |||||||||||
| WH150 | Portalloy® Mill | 6.05 | 1/2 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 116,000 | 15,300 | 882 | |||||||||||
| WH150HD | Portalloy® Mill | 6.05 | 5/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 168,000 | 16,200 | 882 | |||||||||||
| WH157 | Portalloy® Mill | 6.05 | 5/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 161,000 | 18,200 | 882 | |||||||||||
| WH166 | Portalloy® Mill | 6 | 3/8 | 1 3/4 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 5/8 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 9,600 | 882 | |||||||||||
| WH720S | Portalloy® Mill | 6 | 5/16 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Carbon Steel, Heat Treated | 1 3/8 | 1 | Carbon Steel, Heat Treated | 47,200 | 5,500 | 789 | |||||||||||
| WH720SH | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 7/16 | 1 | Carbon Steel, Heat Treated | 67,000 | 5,900 | 789 | |||||||||||
| WH78 | Portalloy® Mill | 2.609 | 1/4 | 1 1/8 | OFFSET | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | 1 1/8 | Carbon Steel, Heat Treated | 30,000 | 3,500 | 882 | |||||||||||
| WH78-4 | Portalloy® Mill | 4 | 1/4 | 1 1/4 | OFFSET | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | 1 1/8 | Carbon Steel, Heat Treated | 36,000 | 3,500 | 882 | |||||||||||
| WH78HD | Portalloy® Mill | 2.636 | 3/8 | 1 1/4 | OFFSET | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 1 | 7/8 | Carbon Steel, Heat Treated | 42,700 | 3,940 | 882 | |||||||||||
| WH82 | Portalloy® Mill | 3.075 | 1/4 | 1 1/4 | OFFSET | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 1 1/16 | 1 1/4 | Carbon Steel, Heat Treated | 36,000 | 4,400 | 882 | |||||||||||
| WH82HD | Portalloy® Mill | 3.075 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 5/8 | Alloy Steel, Heat Treated | 1 1/16 | 1 | Carbon Steel, Heat Treated | 68,000 | 4,900 | 882 | |||||||||||
| WH82XHD | Portalloy® Mill | 3.075 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Induction Hardened | 1 1/4 | 1 | Carbon Steel, Heat Treated | 62,000 | 5,900 | 882 | |||||||||||
| WHC106 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 7,200 | 882 | |||||||||||
| WHC111+ | Portalloy® Mill | 4.76 | 3/8 | 1 3/4 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 2 | Carbon Steel, Heat Treated | 77,000 | 8,850 | 882 | |||||||||||
| WHC124 | Portalloy® Mill | 4 | 3/8 | 1 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 7,200 | 882 | |||||||||||
| WHC132 | Portalloy® Mill | 6.05 | 1/2 | 2 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 115,000 | 15,300 | 882 | |||||||||||
| WHC157 | Portalloy® Mill | 6.05 | 5/8 | 2 1/2 | STRAIGHT | Carbon Steel, Heat Treated | 1 1/8 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 161,000 | 18,200 | 882 | |||||||||||
| WHC78 | Portalloy® Mill | 2.609 | 1/4 | 1 1/8 | STRAIGHT | Carbon Steel, Heat Treated | 1/2 | Alloy Steel, Heat Treated | 7/8 | 1 1/8 | Carbon Steel, Heat Treated | 30,000 | 3,500 | 882 | |||||||||||
| WHC82 | Portalloy® Mill | 3.075 | 1/4 | 1 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 9/16 | Alloy Steel, Heat Treated | 1 1/16 | 1 1/4 | Carbon Steel, Heat Treated | 36,000 | 4,400 | 882 | |||||||||||
| WHX106 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Induction Hardened | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 7,200 | 882 | |||||||||||
| WHX124 | Portalloy® Mill | 4 | 3/8 | 1 1/2 | OFFSET | Carbon Steel, Heat Treated | 3/4 | Alloy Steel, Induction Hardened | 1 1/4 | 1 1/2 | Carbon Steel, Heat Treated | 69,000 | 7,200 | 882 | |||||||||||
| WHX132 | Portalloy® Mill | 6.05 | 1/2 | 2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 115,000 | 15,300 | 882 | |||||||||||
| WHX150 | Portalloy® Mill | 6.05 | 1/2 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 116,000 | 15,300 | 882 | |||||||||||
| WHX155 | Portalloy® Mill | 6.05 | 9/16 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/8 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 145,000 | 17,750 | 882 | |||||||||||
| WHX157 | Portalloy® Mill | 6.05 | 5/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/8 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 161,000 | 18,200 | 882 | |||||||||||
| WHX157XHD | Portalloy® Mill | 6.05 | 5/8 | 3 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 200,000 | 33,000 | 882 | |||||||||||
| WHX159 | Portalloy® Mill | 6.125 | 5/8 | 3 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 2 | 2 3/4 | Carbon Steel, Heat Treated | 230,000 | 20,250 | 882 | |||||||||||
| WHX200 | Portalloy® Mill | 6.05 | 5/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 190,000 | 20,225 | 882 | |||||||||||
| WHX2012A | Portalloy® Mill | 12 | 5/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 200,000 | 33,000 | 882 | |||||||||||
| WHX3012 | Portalloy® Mill | 12 | 5/8 | 3 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 1 3/4 | 2 3/4 | Carbon Steel, Heat Treated | 200,000 | 33,000 | 882 | |||||||||||
| WHX5121HF | Portalloy® Mill | 9 | 1 1/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 2 1/2 | 3 1/4 | Carbon Steel, Heat Treated | 205,000 | 27,600 | 788 | |||||||||||
| WHX5157HF | Portalloy® Mill | 6.05 | 5/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/8 | Alloy Steel, Induction Hardened | 2 1/2 | 2 1/2 | Carbon Steel, Heat Treated | 117,000 | 18,200 | 788 | |||||||||||
| WHX6067HF | Portalloy® Mill | 9 | 3/4 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 2 1/2 | 3 1/4 | Carbon Steel, Heat Treated | 195,000 | 24,000 | 788 | |||||||||||
| WHX6121HF | Portalloy® Mill | 9 | 1 1/8 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 1 1/4 | Alloy Steel, Induction Hardened | 2 1/2 | 3 1/4 | Carbon Steel, Heat Treated | 205,000 | 27,600 | 788 | |||||||||||
| WR106 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel | 47,000 | 6,200 | 882 | |||||||||||
| WR110 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 3/4 | Carbon Steel | 47,000 | 6,750 | 882 | |||||||||||
| WR111+ | Portalloy® Mill | 4.76 | 3/8 | 1 3/4 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 2 | Carbon Steel | 52,000 | 7,500 | 882 | |||||||||||
| WR124 | Portalloy® Mill | 4 | 3/8 | 1 1/2 | OFFSET | Carbon Steel | 3/4 | Alloy Steel, Heat Treated | 1 1/4 | 1 1/2 | Carbon Steel | 47,000 | 6,200 | 882 | |||||||||||
| WR132 | Portalloy® Mill | 6.05 | 1/2 | 2 | OFFSET | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel | 78,000 | 13,000 | 882 | |||||||||||
| WR150 | Portalloy® Mill | 6.05 | 1/2 | 2 1/2 | OFFSET | Carbon Steel | 1 | Alloy Steel, Heat Treated | 1 3/4 | 2 3/4 | Carbon Steel | 78,000 | 13,000 | 882 | |||||||||||
| WR78 | Portalloy® Mill | 2.609 | 1/4 | 1 1/8 | OFFSET | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 7/8 | 1 1/8 | Carbon Steel | 20,000 | 3,000 | 882 | |||||||||||
| WR78-4 | Portalloy® Mill | 4 | 1/4 | 1 1/4 | OFFSET | Carbon Steel | 1/2 | Alloy Steel, Heat Treated | 7/8 | 1 1/8 | Carbon Steel | 25,900 | 3,000 | 882 | |||||||||||
| WR82 | Portalloy® Mill | 3.075 | 1/4 | 1 1/4 | OFFSET | Carbon Steel | 9/16 | Alloy Steel, Heat Treated | 1 1/16 | 1 1/4 | Carbon Steel | 25,000 | 3,800 | 882 | |||||||||||
| WS106 | Portalloy® Mill | 6 | 3/8 | 1 1/2 | OFFSET | Stainless Steel | 3/4 | Stainless Steel | 1 1/4 | 1 1/2 | Stainless Steel | 47,000 | 7,200 | 787 | |||||||||||
| WS124 | Portalloy® Mill | 4 | 3/8 | 1 1/2 | OFFSET | Stainless Steel | 3/4 | Stainless Steel | 1 1/4 | 1 1/2 | Stainless Steel | 47,000 | 7,200 | 787 | |||||||||||
| WS132 | Portalloy® Mill | 6.05 | 1/2 | 2 | OFFSET | Stainless Steel | 1 | Stainless Steel | 1 3/4 | 2 3/4 | Stainless Steel | 78,000 | 13,000 | 787 | |||||||||||
| WS78 | Portalloy® Mill | 2.609 | 1/4 | 1 1/8 | OFFSET | Stainless Steel | 1/2 | Stainless Steel | 7/8 | 1 1/8 | Stainless Steel | 20,000 | 3,500 | 787 | |||||||||||
| WS82 | Portalloy® Mill | 3.075 | 1/4 | 1 1/4 | OFFSET | Stainless Steel | 9/16 | Stainless Steel | 1 1/16 | 1 1/4 | Stainless Steel | 25,000 | 4,200 | 787 | |||||||||||
| ZA2178A | SBR | 6 | 3/8 | 2 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 2 3/4 | B- Plain with Hubs | Carbon Steel, Heat Treated | 85,000 | 7,080 | 783 | |||||||||
| ZA2184+ | SBR | 6 | 3/8 | 2 | OFFSET | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 3 | A- Plain | Carbon Steel, Heat Treated | 85,000 | 6,500 | 783 | |||||||||
| ZA2198 | SBR | 6 | 1/2 | 2 1/4 | STRAIGHT | Carbon Steel, Heat Treated | 7/8 | Alloy Steel, Heat Treated | 1 1/4 | Carbon Steel, Heat Treated | 2 3/4 | B- Plain with Hubs | Carbon Steel, Heat Treated | 100,000 | 7,850 | 783 | |||||||||
| ZA2800 | SBR | 8 | 1/2 | 2 3/4 | STRAIGHT | Carbon Steel, Heat Treated | 1 | Alloy Steel, Heat Treated | 1 1/2 | Carbon Steel, Heat Treated | 3 1/2 | A- Plain | Carbon Steel, Heat Treated | 125,000 | 9,840 | 783 | |||||||||
| ZA9184 | SBR | 6 | 1/2 | 2 1/2 | OFFSET | Carbon Steel, Heat Treated | 15/16 | Alloy Steel, Heat Treated | 1 1/4 | Alloy Steel, Heat Treated | 3 | B- Plain with Hubs | Carbon Steel, Heat Treated | 125,000 | 8,400 | 783 | |||||||||
